EQUIPMENT LIST
Abrasive Waterjet Machine
CMM
Mitutoyo Profile Projector
Feeler CNC Lathe
CNC Lathe
First Vertical Machining Center
Feeler Vertical Machining Center
CNC Machining Center
Vertical CNC Machining Center
FADAL VMC 4020
V 20 Vertical Mill
Correa Universal Mill
Cylindrical and Surface Grinders
Harrison Lathe
Colchester Lathe
Baxter vertical and horizontal saws
Bridgeport Mill
Kingsland Iron Worker
Ward Turret Lathe
Heat Treat Oven
Welding Equipment
Plasma Cutter
Radial Drill
KBC Lathe
Darex M5 Drill Grinder
Hardness Tester
HP DesignJet 2500CP
Clark Forklift
Return to home page

Abrasive Waterjet Machine:

Click here to view manufacturer's website www.omax.com

Other waterjet links www.waterjets.org

  • Machining complex profiles to extremely close tolerances

  • 4 ft x 8 ft capacity

  • Able to cut any material

  • No hard edges and has a smooth satin finish

  • Accepts dxf files

  • Able to cut paper thin to 10" thick in steel

  • Future technology put into practice for today's machining advancements

  • Accurate repeatability for production quantities

    •

    CLICK HERE TO SEE PICTURES OF PARTS MADE BY THE WATERJET





Giddings & Lewis Sheffield Co-ordinate Measuring Machine:

  • Model Cordax 1808-M MEA

  • 40" x 20" x 20" capacity

  • Measure Max Plus software with
    CADPath, Form Fit and Reverse Engineering

  • Qualified & Certified by Giddings & Lewis 2007

  • NIST# 821/264885-01







Mitutoyo Profile Projector PH-350H:



  • Model: PH-350H Optical comparator

  • Used for profile measurements and inspection
















Feeler CNC Lathe:

  • Model FTC-20

  • 345mm Swing

  • 274mm Turning Diameter

  • 380mm Z Travel

  • 12 Position automatic tool changer

  • 25 HP







Amera Seiki CNC Lathe:

  • Model TC-3LS

  • 40 HP Main Spindle 3000 RPM

  • 15 HP Sub-Spindle 4500 RPM

  • 13" Maximum Diameter x 23.620" Length

  • 12 Tool Turret (Index Time .6 sec) Direction Logic

  • Electronic Tool Setter

  • Chip Conveyor

  • Cad/Cam programming services







First MCV1100 Vertical Machining Center:

  • 43.3" x 23.6" x 22.0" Travel

  • 10,000 RPM Direct Drive

  • 20 HP Spindle Drive

  • 24 Tool Changer

  • Fully Enclosed

  • Chip Flush & Conveyor System



















Feeler Vertical Machining Center:

  • Model FV 1000SE

  • 15 HP Main Spindle 8000 RPM

  • 40" x 20" x 20" Travel

  • 22 automatic tool change carrousel

  • Fully enclosed guard

  • Chip tray

  • BT 40 tooling

  • Cad/Cam programming services







CNC Machining Center:

  • Model MCV641

  • Travel 24" x 36" x 20" vertical machining center

  • Manufactured by First

  • 10 HP

  • 3 axis CNC Fanuc control

  • 3D surfacing and CAD programming

  • Rigid tapping

  • 4 axis wired

  • Fully enclosed

  • 18 automatic tool changer










Vertical CNC Machining Center:




FADAL VMC 4020 Machining Center:




  • 10,000 RPM

  • 40"x 20"x 20" machining center

  • 21 tool changer

  • 4th axis hardwired

  • CAM operated 3-axis surfacing

  • FADAL CNC 88 control

  • Fully enclosed

  • Chilled spindle

  • Modified BT tooling











V 20 VERTICAL MILL MANUFACTURED BY FIRST:






CORREA UNIVERSAL MILL:

  • Nicolas Correa model #F2UE

  • Vertical and horizontal 40 taper spindles

  • 3 axis power feed

  • Universal attachments

  • Dividing head

  • 52" x 12" table

  • 3 axis digital readouts

  • Gear driven







CYLINDRICAL AND SURFACE GRINDERS:

Universal internal and external cylindrical grinding:

  • Brown & Sharpe

    • -10" x 20" external capacity

    -hydraulic feed








    Surface grinding:

    • K.O. Lee Grinder

      • -6" x 18" capacity

      -automatic hydraulic feed







      Chevalier Surface Grinder:

      • 3A 1020

        • -10" x 20" capacity

        -automatic 3- axis surface grinder










Harrison Lathe:



  • Model M450

  • 24" swing over gap x 60" long

  • 3" through bore

  • 13 horsepower

  • Digital readouts

  • Taper turning attachment






Colchester Lathe:



  • Model: Triumph VS 2500

  • 23" swing over gap x 50" long

  • 2.1" through bore

  • 10 horsepower variable speed

  • Digital readouts

  • Taper turning attachment






Baxter Vertical and Horizontal Saws:

  • Baxter Verticut:

    • -vertical saw











  • Baxter Horizontal 280

    • -12" round capacity












Bridgeport Mill:

  • 9" x 24"

  • Digital readouts

  • Variable speed















KINGSLAND IRON WORKER:

  • Model #65XS

  • 65 ton

  • 5 station

  • Bending 1/2" x 18"

  • Shearing= 12" x 5/8" and 8" x 3/4"

  • Angle cutting- 1/2" x 5-1/8" x 5-1/8"

  • Notching 90 degrees- 3/8" x 2-3/8"

  • Punching capacity- 1-1/2" x 7/16"







Ward Turret Lathe:




  • Ward model #2DS

  • 14" swing x 20"

  • 6 position turret

  • Digital readouts

  • Auto feed carriage and turret








HEAT TREAT OVEN:


  • Model: RECCO dual chamber process furnace

  • 12" x 8" x 20" Capacity

  • 2250/1250 degrees F

  • Used for heat treat and tempering

  • Digital controls for temperature and timing










Welding Equipment:


Mig Aluminum Welding
- Miller 200


Mig Welding- Lincoln 255

Tig Welding- Licoln 275


Arc Welding- Lincoln 250







Plasma Cutter:

  • Model: CutMaster 38 power supply

  • SL60 Air plasma cutting torch

  • Portable








Radial Drill:

  • 90-1120

  • 24" arm


















KBC Lathe:

  • 12" x 36"

  • 6" chuck















Darex M5 Drill Grinder:

  • Large bit fixture- up to 1 1/8"

  • Step drill adapter

  • Able to sharpen single and double point to any degree










HARDNESS TESTER:

  • Both RC and RB scales








HP DesignJet 2500CP:


  • Model: 2500CP

  • Prints poster-size images up to 3' x 150ft

  • Accepts a wide range of media including coated papers, glossy photo papers, vinyl and more...








Clark Forklift:


  • Model: EC520

  • 4000 LB capacity @ 24" load center

  • 42" forks with extensions

  • Electric
